Profession Technical Specification
| Garbage Compactor Truck Dongfeng Kinland (7,000 litres) | ||
| General | Vehicle Brand | CEEC TRUCKS |
| Chassis Brand | Dongfeng | |
| Overall Dimension | 6960X2250X2650 mm | |
| GVW / Kerb Weight | 104,50 kg / 6,405 kg | |
| Cab | Cab Capacity | 2,3 persons allowed |
| Engine | Fuel Type | Diesel |
| Engine Brand | Dongfeng engine | |
| Power | 123 Hp (91 KW) | |
| Displacement | 3856 ml | |
| Emission Standard | Euro Ⅲ | |
| Chassis | Drive Type | 4x2 left hand drive |
| Transmission | 5 front and 1 reverse | |
| Wheelbase/No. of axle | 3800 mm / 2 | |
| Tyre Specification | 7.50-16 | |
| Tyre Number | 6 tyres and 1 spare tyre | |
| Max Speed | 95 km/h | |
| Paint | Metallic paint | |
| Superstructure and the main characteristic |
Garbage box Capacity | 7,000 Litres ( 1,838gallons) |
| Garbage box Material | Carbon steel | |
| 1: Can choose 240L（single bin、double bins）or 360L、660L、1100L standard bin lifting and turnover mechanism，can also choose ground hopper and other kinds of loading mechanism. | ||
| 2: With manual and automatic two sets of control method, the operator can control in the cabin, in the middle side or the back of the truck , very convenient and efficient. | ||
| 3: With working device of emergency braking stop button. | ||
| 4: Garbage body use frame design, elegant, strong structure, large effective capacity. | ||
| 5: Equipped with special collection box, sewage directly into the sewage tank in the process of compression, that is effectively prevent second pollution caused by sewage leaks. | ||
| 6: Through hydraulic system design, the truck achieve the function of two-way garbage compression, that is improve the compressibility ,make the compression ratio up to 1:2.5,the garbage can reach more then 600～800kg／m3 after compression. | ||
| 7: All other standard accessories: Tool kit, English manual… | ||
Function & Usage
Compressed garbage truck (also called waste compactor truck, garbage compactor truck, trash compactor, refuse collection truck, compactor garbage truck, rubbish truck, bin wagon, dustcart ,bin lorry , waste collection vehicle) is designed to collect and transport municipal solid waste.
Garbage compactor is composed of hermetical garbage box, hydraulic system and operating system, which could apply pressure to the waste to break down bulky items , to load and transport more garbage by one time. Dirty liquid flows in waste sink, perfectly preventing re-pollution. When arriving at destination , the garbage can be dumped completely. It is ideal solution for solid waste collection.
The compression garbage truck controlled by the integration of the machinery, electricity and hydraulic , with manual control system. Crush the garbage through filling, pushing and spading, finally make the waste compaction in the dustbin.
Advanced Features
---- Dongfeng chassis, perfect performance.
---- Dongfeng engine, super powerful; reliable performance.
---- Nice shape, rational structure
---- High quality hydraulic system
---- Massive, durable, perfect performance
---- Prolonged service life
All CEEC TRUCKS produced garbage compactor trucks have following shipping method:
Preliminary drawing for CEEC TRUCKS refuse compression trucks:
