JAC GALLOP 4X2 Tipper truck

products

JAC 4x2 dump truck, JAC 4x2 LHD chassis, FAST 8-shift manual gearbox, famous Chinese brand WEICHAI 160HP diesel engine, high strength steel tipper body, with HYVA or domestic hydraulic lifter optional. All painting and logos depend on customer's requirement.


Product Details

 Applications:
JAC 4X2 Dumper truck (also called JAC 6-wheel tipper truck, JAC 4X2 dump truck, hot sale tip trucks JAC, JAC one axle dump truck, good quality dump truck JAC, 10Tons Sand tipping truck, JAC small tipper lorry, JAC tipper) is a truck used for transporting oose material, such as sand, gravel, coal, dirt, etc.


CEEC TRUCK dump truck is manufactured with the cutting-edge technology and components in the world such as WABCO double-cylinder air compressor, brake valve, HYVA front or middle hydraulic system, etc.

 Key Features:

---- JAC heavy duty chassis, perfect performance
---- WEICHAI diesel engine, super powerful; reliable performance, no overhaul within 100,000 km.
---- Payloading from 20ton to 100 tons.
---- Easy operation and easy maintenance.
---- Various types of tipper body are available.


 Specifications:



Hot sale JAC Dump truck
General	Vehicle Brand	CEEC TRUCKS
	Chassis Brand	JAC
	Overall Dimension	6720 * 2400 * 3300 mm
	GVW / Kerb Weight	16,000kg / 7,950kg
Cab	Cab Capacity	3 persons allowed
	Air Conditioner	Heating/cooling air conditioner
Engine	Fuel Type	Diesel
	Engine Brand	WEICHAI diesel engine
	Power	160 HP (115 KW)
	Displacement	4088 ml
	Emission Standard	Euro 4 or 5
Chassis	Drive Type	4X2 (LHD or RHD)
	Transmission	FAST 8 speed levers with 2 reverse
	Wheelbase/No. of axle	3600 mm / 2
	Tire Specification	9.00R20
	Tire Number	6 tires and 1 spare tire
	Max Speed	95 km/h
	Paint	Metallic paint
Superstructure	Pay loading capacity	10 Tons
	Cargo body	4200*2200*800
	Thickness of cargo body	Option 1: Bottom 8mm, Side 6mm Option 2: Bottom 10mm, Side 8mm
	Cylinder type	T Type or Domestic 220 or HYVA 200
	Lifting system	Middle or Front
	Control	in the cabin
	Color & LOGO	According to wish
	All standard accessories: All steel body with drop sides. Auto release removable tailgate. Ladder, warning lights, PTO  fire extinguisher, basic tool kit, English manual……
Optional	** Back alarm and Camera can be equipped. ** Other tipper body can be choose. ** Other material and plate thickness can be choose.

Customer Case

★ Euro 4 or 5 type, WEICHAI engine, fuel consumption save 20%
★ FAST 8-shift manual mechanical transmission gearbox
★ Dumper truck body material can be High strength carbon steel Q345 material, with thickness over 6mm

★ 12 months fast moving spare parts for FREE

★ Authorized JAC tipper trucks exporter

★ Training service for JAC dumper trucks

Factory Advantage

China best dump truck supplier and exporter, we supply the best quality JAC 4*2, 6*4, 6*6, 8*4, 8*8, etc. We can ensure the fast delivery time and 12 months guarantee for our tipper trucks. Our JAC heavy trucks are sold to more than 80 countries including Eastern Europe and CIS countries, Africa, Southeast Asia, Central and South America, Middle East, etc.

---- Maximize save your sea freight.

---- Professional guidance on your importing documents.
---- Safety, Quickly, Timely



---- Service more than 60 countries.
----  Professional guidance on your importing documents.
----  CO, FORM E, FORM P, Pre-shipping Inspection...
