As the most professional sanitation equipment manufacturer in China, we CEEC TRUCKS can provide all kinds of sanitation trucks, including garbage compactor truck, road sweeper truck, water tanker truck; combined jetting truck; high pressure jetting truck; cesspit emptier truck; roll on roll off truck. DFAC brand 4CBM mini water sprinkler tanker trucks use DongFeng brand 3300mm wheelbase chassis, equipped with CHAOCHAI 95HP engine, 5-shift transmission gearbox, 4mm thickness carbon steel Q235 material made oval water tank, all with anti-rust and anticorrossion treatment. Also at the rear of the truck tank installed Pesticide Spraying system.
|
Product model and name
|
CEEC5060GSS3 water truck
|
|||||
|
Gross weight(Kg)
|
6495
|
Drive type
|
4X2
|
|||
|
Payload(Kg)
|
3250,3315
|
Overall dimension(mm)
|
5990X1960X2380
|
|||
|
Curb weight(Kg)
|
3050
|
Cab seats
|
2,3
|
|||
|
Approach/departure angle(°)
|
17/13
|
Front/rear hang(mm)
|
1032/1658
|
|||
|
Axle No.
|
2
|
Wheelbase(mm)
|
3300
|
|||
|
Axle load(Kg)
|
2620/3875
|
Max speed(Km/h)
|
90
|
|||
|
Chassis specification
|
||||||
|
Chassis model
|
EQ1060TJ20D3
|
Manufacturer
|
Dongfeng Motor Co., Ltd
|
|||
|
Brand name
|
Dongfeng
|
Dimension(mm)
|
5820X1940X2080
|
|||
|
Tyre specification
|
7.00-16
|
Tyre No.
|
6
|
|||
|
Steel spring number
|
8/9+5,6/8+4
|
Front track base(mm)
|
1506
|
|||
|
Fuel type
|
Diesel
|
Rear track base(mm)
|
1466
|
|||
|
Emission standard
|
Euro 3
|
Transmission
|
5 forward gear,1 reverse
gear
|
|||
|
Cab
|
Luxurious interior trim with
dashboard and air condition.
|
|||||
|
Engine model
|
Engine manufacturer
|
Displacement(ml)
|
Power(Kw)
|
|||
|
CY4102-C3F
|
Dongfeng Chaoyang Chaochai
Power Co.,Ltd
|
3856
|
70
|
|||
|
Performance
|
||||||
|
Tank volume(m³)
|
4
|
Tank material
|
Carbon steel Q235
|
|||
|
Water pump model
|
65QZ40/45
|
Water pump flow(m³/h)
|
40
|
|||
|
Watering width(M)
|
≥14
|
Water cannon range (M)
|
≥28
|
|||
|
Feature and Application
|
||||||
|
1).Equipped with high power
self-suction water pump that characterized by high-pressure and fast speed
suction.
2).Equipped with front, rear
and side sprinklers and high position sprinkler, and rear working platform.
3).The water cannon which is
installed on the working platform can rotate by 360 degree and the water flow
can be adjusted into various rain shape. There are straight shape, heavy
rain, moderate rain and drizzle etc. The max range can reach 30M.
4).Equipped with fire coupling,
flow valves, filter screen and water level gauge.
5).According to customers’
request, the crane, high working platform and spraying machine also can be
equipped.
6).Mainly used for washing on urban roads, watering and
greening on trees, green belts and lawn and dust full of construction sites.
And also used for drinking water delivery and firefighting function etc.
|
||||||
