CEEC products——best 3CBM water tanker truck for export

CEEC sprinkler truck realizes cleaning and cooling through high-pressure water, which washes the dust on the road and then takes it way through the drainpipe. This type street sprinkler with multi-function patterns and widely used for environmental protection city works and green belt.

CEEC water sprinklers with low & flat high water flow washing, high speed and high efficiency. Water sprinkler system with pneumatic pressure, not weakness hydraulic pressure designing.

Street sprinkling truck tank body inside with metallic printings to keep the tank from rusting. Optional for choose stainless steel tank of CEEC street sprinkling truck. Water tanker truck mounted with flat ellipse figure, side with round arc shape, together with quality print makes the lawn sprinkler truck harmonious and good appearance.

Parameter:

Water Tank Technical Specification
Water Tank	Equipped with rear working platform and water cannon
Tank Capacity (m3)	3
Tank Overall size (L x W x H) (mm)	3200 x 1400 x 920
Sprinkling Width (mm)	14000
Pump Suction Lift (mm)	7000
Water Flow Rate (m3/h)	90
Tank Material	Carbon steel made of Q235B
Chassis Specification
Truck Model	EQ1050TJ20D2
Engine
Model	YC4F90-30
Type	Four-cylinder, water-cooled, mechanical injection
Rated power (Hp)	90
Transmission
Model	DF-5
Type	5 Forward & 1 Reverse Speed
Travelling
Drive Model	4x2
Steering Wheel Position	Left hand drive
Max. Travelling speed	95
Dimension
Overall Size (mm)	5850 x 1900 x 2350
Tyre Size	7.00-16
Wheel Base(mm)	3000
Weight
Curb Weight (kg)	2865
Payload Capacity (kg)	3000
Why choose CEEC water tankers? Dust control on construction sites; our water trucks have side & front sprayers to cover a large area. Watering of plants & grass along roadsides or in parks & newly planted areas. On film & photo shoots where rain effect or wet areas are required. Corporate Events & Festivals; to fill water barricades or provide water for catering & cleaning. Large pool fills for public or private use. This truck has front dash, rear spraying , side sprinkler, high position shower, self-discharge valve, with fire hose coupling. The high-power water cannon is installed on the platform. It can adjust to heavy rain, Moderate rain, drizzle and mist. Meanwhile, the vehicle can be used as high-pressure cleaning , emergency fire-fighting, pump station etc.
