Hot sale 10cbm concrete mixer, ISUZU GIGA 6x4 LHD chassis, ISUZU 380HP diesel engine, ZF 16-shift manual gearbox, as for main parts motor, pump, reducer, which can have brand optional as Eaton, PMP, Rexroth, Bonfiglioli, etc, painting and logos depend on request.
Product Details
Applications:
ISUZU GIGA Transit Mixer truck (also called transit mixer vehicle, concrete delivery truck, ISUZU GIGA transit mixing vehicle, cement mixer truck manufacturer, concrete mixing truck, cement transportation truck, concrete truck for sale ) is designed for both overseas and domestic high end heavy truck markets. In order to prevail over its rivals in the global competition, key components of the tipper truck are designed in close collaboration with top suppliers in the world.
CEEC TRUCKS mixer truck is manufactured using the cutting-edge technology and components in the world such as EATON, Rexroth, PMP, etc.
Key Features:
---- ISUZU heavy duty chassis, perfect performance
---- ISUZU engine, super powerful; reliable performance, no overhaul within 100,000 km.
---- Pay loading from 3CBM to 18CBM.
---- Easy operation and easy maintenance.
---- Various types of Hydraulic main parts are available.
Specifications: ---- ISUZU engine, super powerful; reliable performance, no overhaul within 100,000 km.
---- Pay loading from 3CBM to 18CBM.
---- Easy operation and easy maintenance.
---- Various types of Hydraulic main parts are available.
Cement Mixer Truck ISUZU GIGA (10 cbm)
|
||
General
|
Vehicle Brand
|
CEEC
|
Chassis Brand
|
ISUZU
|
|
Overall Dimension
|
8200 * 2500 * 3570 mm
|
|
GVW / Kerb Weight
|
25,000kg / 11,100kg
|
|
Cab
|
Cab Capacity
|
3 persons allowed
|
Air Conditioner
|
Heating/cooling air conditioner
|
|
Engine
|
Fuel Type
|
Diesel
|
Engine Brand
|
ISUZU
|
|
Power
|
380 HP (280 KW)
|
|
Displacement
|
9839 ml
|
|
Emission Standard
|
Euro 5
|
|
Chassis
|
Drive Type
|
6X4 (left hand drive)
|
Transmission
|
ZF 16 speed levers with 1
reverse
|
|
Wheelbase/No. of axle
|
4565+1370 mm / 4
|
|
Tire Specification
|
11.00R20
|
|
Tire Number
|
10 tires and 1 spare tire
|
|
Max Speed
|
95 km/h
|
|
Paint
|
Metallic paint
|
|
Superstructure
|
Mixer tank volume
|
10 cubic meter
|
Barrel wall Thickness
|
5 mm
|
|
| Barrel wall material | T520JJ | |
Loading speed
|
≥ 1.2
|
|
Discharging speed
|
≥ 2.7
|
|
Rest rate
|
≤ 1
|
|
Control
|
Both side with hydraulic control
|
|
| Pump | Import Brand | |
| Motor | Import Brand | |
| Reducer | Import Brand | |
Color & LOGO
|
According to wish
|
|
All standard accessories: All tools. .
Ladder, warning lights, PTO fire extinguisher, basic tool kit, English manual……
|
||
Optional
|
** Back alarm and Camera can be equipped.
** Other body capacity can be choose.
** Other material and plate thickness can be choose.
| |
Customer Case
★ ISUZU engine, Euro 5 emission, strongly 380ps, and 16 shift manual mechinical gearbox
★ Curb weight approx 11100kg and rated mixing capacity can be up to 5CBM, very good performance
★ Specific heavy truck metallic framework and stressed-skin construction, processing security of same level of European automobiles
★ High strength carbon steel Q345 material, with thickness over 6mm
★ Americal brand Eaton Hydraulic Pump, Hydraulic Motor, and best performed Germany Rexroth Reducer.
Factory Advantage
CEEC TRUCKS is a full-service
supplier of concrete mixer trucks in China. Our transit mixer trucks are sold to more than 80 countries
including Eastern Europe and CIS countries, Africa, Southeast Asia,
Central and South America, Middle East, etc.
---- Maximize save your sea freight.
---- Maximize save your sea freight.
---- Professional guidance on your importing documents.
---- Safety, Quickly, Timely
---- Service more than 60 countries.
---- Professional guidance on your importing documents.
---- CO, FORM E, FORM P, Pre-shipping Inspection...
---- Safety, Quickly, Timely
---- Service more than 60 countries.
---- Professional guidance on your importing documents.
---- CO, FORM E, FORM P, Pre-shipping Inspection...
