ISUZU FTR 12000L vacuum suction truck export to Africa, ISUZU 4HK1 model 205HP diesel engine, isuzu MLD 6-shift manual gearbox, high strength steel material tanker can be up to 12 cbm, Optional domestic WEILONG vacuum pump and import JUROP / BP vacuum pump, hydraulic lifting device for waste discharge, painting and logos depend on request.
Applications:
Vacuum Tanker Truck ISUZU
(also called sewer sucker, vacuum truck, septic tank truck, cesspit
emptier, vacuum pumper truck, vacuum suction truck, sewage suction
truck) is
used to collect, transport and discharge liquid such as dirty water,
sludge, septic, crude oil, and solid stuff such as small stones, bricks
as well. It is suitable for cleaning the sewer, cesspit, cesspool,
gully, etc. It is widely used in environment and sanitation field.
CEEC TRUCKS
12CBM Cesspit Emptier truck which use WEILONG or Italy JUROP / BP
vacuum pump, for 10CBM or more recommend Double Pump for efficiently
working.
The septic tanker truck can be equipped with cabin Pneumatic Control for easy operation.
Key Features:
---- ISUZU FTR/FVR chassis, perfect performance
---- ISUZU 4HK1 diesel engine, super powerful, no overhaul within 100,000 km.
---- Vacuum Tanker body capacity from 3 to 20 Cublic Meter.
---- Easy operation and easy maintenance.
---- Various types of refuse container lifter are available.
Specifications:
| General |
Vehicle Brand |
CEEC TRUCKS |
| Chassis Brand |
ISUZU |
|
| Overall Dimension |
8200 * 2500 * 2820 mm |
|
| GVW / Kerb Weight |
16,000kg / 7,500kg |
|
| Cab |
Cab Capacity |
2 persons allowed |
| Air Conditioner |
Heating/cooling air conditioner |
|
| Engine |
Fuel Type |
Diesel |
| Engine Brand |
4HK1-TC |
|
| Power |
205 HP (140 KW) |
|
| Displacement |
5193 ml |
|
| Emission Standard |
Euro 4 or 5 |
|
| Chassis |
Drive Type |
4X2, (left hand drive) |
| Transmission |
Manual MLD 6 speed levers with 1 reverse |
|
| Wheelbase/No. of axle |
4500 mm / 2 |
|
| Tire Specification |
10.00-20 |
|
| Tire Number |
6 tires and 1 spare tire |
|
| Max Speed |
90 km/h |
|
| Paint |
Metallic paint |
|
| Superstructure |
Body capacity |
12000 liters |
| Tanker Material |
Carbon Steel |
|
| Suction Head pipeline |
7 m |
|
| Vacuum Pump brand |
WEILONG / Italy BP / Domestic Pump |
|
| Vacuum Pump advantage |
High efficient, vacuum rate 93%, quick suction and discharge, suction lift 6m |
|
| Hose |
High quality, wire strengthened hose |
|
| Control panel |
English or Your language |
|
| All standard accessories: Inlet pipeline, discharge nozzle, cabin pneumatic control box, basic tool kit, English manual…… |
||
| Optional |
** Back alarm and Camera can be equipped. ** Standard carbon steel, stainless steel optional. ** Standard WEILONG vacuum pump, Italy vacuum pump optional |
|
Vacuum Trucks |
|||
|
|
|
|
|
|
|
|
Model |
Engine Model |
Rated Power |
Payload |
Driving Model |
4KH1CN5LS |
98 HP |
6,000 L |
4×2 |
|
4HK1-TC51 |
190 HP |
8,000 L |
4×2 |
|
4HK1-TC50 |
205 HP |
10,000 L |
4×2 |
|
WD615.30 |
300 HP |
10,000 L |
6×4 |
|
WD615.34 |
340 HP |
20,000 L |
6×4 |
|
CEEC5200-ZZ |
WD615.38 |
380 HP |
20,000 L |
6×4 |
(Factory price ISUZU septic cleaning trucks for sale )
CEEC
TRUCKS is a professional vacuum sucker trucks manufacturer. We can
provide ISUZU vacuum tanker truck, HOWO sewage tanker truck, FOTON septic empiter, Dongfeng septic pumper truck, etc.
We also customize vacuum tank semi-trailer and vacuum tanker superstructures. The capacity of vacuum
tankers can be 3,000-30,000 liters. Our vacuum sewage trucks are very popular
in Southeast Asia, Middle East, Africa and South America because of the high quality and low price.
Key Words: ISUZU septic vacuum truck, ISUZU sewage suction truck, FTR / FVR sewer sucker, cesspit emptier, gully emptier, vacuum pump truck, gully emptier, waste vacuum tanker, vacuum tanker, gully sucker
---- 12 months FREE part
---- Factory genuine parts supply.
---- 7 days to worldwide by DHL.
---- Service more than 60 countries.
---- Professional guidance on your importing documents.
---- CO, FORM E, FORM P, Pre-shipping Inspection...
CEEC TRUCKS is a leading exporter of vacuum suction trucks in China. We possess over 10-year export experience of septic tanker trucks. We can ensure the fast delivery time and 12 months guarantee for our sewer cleaning trucks. Our cesspool empiters are sold to more than 80 countries including Eastern Europe and CIS countries, Africa, Southeast Asia, Central and South America, Middle East, etc.
---- Maximize save your sea freight.
---- Professional guidance on your importing documents.
---- Safety, Quickly, Timely
Watch CEEC Cesspit Emptier on YOUTUBE
ISUZU Vacuum Sewage truck: https://www.youtube.com/watch?v=qfVKNSmm_S8
https://www.youtube.com/watch?v=HqIoaNAN4iY
Cesspit Emptier Superstructure: https://www.youtube.com/watch?v=Z99YwRpQUm4
https://www.youtube.com/watch?v=jv0x0I4keF0
