JAC 6x4 Tipper Truck

products

Belarus 40Tons tipper truck, JAC 6x4 chassis, FAST 10-shift manual gearbox, famous Chinese brand WEICHAI 310HP diesel engine, high strength steel tipper body, with HYVA or domestic hydraulic lifter optional. All painting and logos depend on requirement.


Product Details

 Applications:
Shacman 6*4 Dump truck (also called heavy duty dump truck, tipper truck, 40tons tipper trucks, Hyva front lifting dump truck, dump truck, construction sand rock dump truck, tipper lorry, tip truck, dump truck tipping, tipper and lorry, tipper lorry) is designed for both overseas and domestic high end heavy truck markets. In order to prevail over its rivals in the global competition, key components of the tipper truck are designed in close collaboration with top suppliers in the world.


CEEC Trucks dump truck is manufactured using the cutting-edge technology and components in the world such as WABCO double-cylinder air compressor, brake valve, HYVA front hydraulic system, etc.

 Key Features:

---- JAC heavy duty chassis, perfect performance
---- WEICHAI diesel engine, super powerful; reliable performance, no overhaul within 100,000 km.
---- Payloading from 20ton to 100 tons.
---- Easy operation and easy maintenance.
---- Various types of tipper body are available.


 Specifications:





JAC 6*4 tipper truck (40 tons)
General	Vehicle Brand	CEEC
	Chassis Brand	FAC
	Overall Dimension	7935 * 2500 * 3500 mm
	GVW / Kerb Weight	25,000kg / 12,450kg
Cab	Cab Capacity	3 persons allowed
	Air Conditioner	Heating/cooling air conditioner
Engine	Fuel Type	Diesel
	Engine Brand	WEICHAI diesel engine
	Power	310 HP (228 KW)
	Displacement	9726 ml
	Emission Standard	Euro 3 or 4
Chassis	Drive Type	6X4, (LHD or RHD)
	Transmission	FAST  10 speed levers with 2 reverse
	Wheelbase/No. of axle	3490+1350 mm / 3
	Tire Specification	11.00R20
	Tire Number	10 tires and 1 spare tire
	Max Speed	85 km/h
	Paint	Metallic paint
Superstructure	Pay loading capacity	40 Tons
	Cargo body	5200*2350*1500
	Thickness of cargo body	Option 1: Bottom 8mm, Side 6mm Option 2: Bottom 10mm, Side 8mm
	Cylinder type	T Type or Domestic 180 or HYVA 150
	Lifting system	Middle or Front
	Control	in the cabin
	Color & LOGO	According to wish
	All standard accessories: All steel body with drop sides. Auto release removable tailgate. Ladder, warning lights, PTO  fire extinguisher, basic tool kit, English manual……
Optional	** Back alarm and Camera can be equipped. ** Other tipper body can be choose. ** Other material and plate thickness can be choose.

Customer Case

★ Manual 10-shift manual gearbox, 10 forward & 2 reverse
★ Expert for producing JAC Dump truck over 10 years with good reputation

★ Carbon steel material

★ 12 months free fast moving spare parts
★ All English version control box, panel, and owner's manual, for easy understanding
★ Training service for JAC tipper trucks
