Advantage for
everyone knows:
Factory: We are the biggest truck
manufacture in suizhou city, HuBei Province, china.
Certificate: All our products passed ISO9001, and CCC
certificate.
Technology: We have advance equipment
for production and best technology.
Warranty: 12 Months or 100,000 Km. Which
comes first with all conditions stipulated under the bid instruction.
As
the most convenient vehicle to transport rock, sand, wood, equipment and other
materiel, Beiben old model NG80 cab mining tipper dump truck has been
widely used in mining, transporting rocks, etc.
China
North Benz 6x4 type 2534 new-power tipper use WEICHAI WP10.336 engine, emission
standard 9726ml, can meet Euro Ⅱ/Ⅲ. The
service brake is drum type, which makes traveling more safety. 12.00-20 tire as
the standard configuration, but consumers can have 12.00R20 tire or tubeless
tire for optional.
Being the most professional beiben 4x2 / 4x4 / 6x2 / 6x4 / 6x6 / 8x4 / 8x8 dump truck manufacturer in China for many years, we have different tipper body for customers’ choose: Standard body; U-section body; Mining rock body; Reinforce rock body; Scoop end type body; Super large body; Body heating body; Refuse body with canopy; Two-way dump body; Shorter type body, etc.
Following
form shows the Technical Specification for China best Oldmodel NG80 cab tipper dump truck:
|
Name
|
Standard configuration
|
|||
|
♦ Drive type:
|
6x4 LHD / RHD
|
|||
|
♦ External outline dimension (mm)
Long x Width x High
|
7828x2500x3310
|
|||
|
♦ Track
|
♦ Front (mm)
|
1995
|
||
|
♦ Rear (mm)
|
1800
|
|||
|
♦ Angle
|
♦ Approaching angle (c)
|
26
|
||
|
♦ Departure angle (c)
|
32
|
|||
|
♦ Overhang
|
♦ Front (mm)
|
1410
|
||
|
♦ Rear (mm)
|
1518
|
|||
|
♦ Minimum ground clearance (mm)
|
339
|
|||
|
♦ Minimum turning diameter (mm)
|
18.2
|
|||
|
♦ Wheelbase (mm)
|
3450+1450
|
|||
|
♦ Maximum speed (km/h)
|
75
|
|||
|
♦ Maximum gradeability (%)
|
30
|
|||
|
♦ Total mass (kg)
|
25000
|
|||
|
♦ Complete vehicle curb (kg)
|
12179
|
|||
|
♦ Carriers quality (mm x mm x mm)
|
5200x2300x1200
|
|||
|
♦ Engine
|
♦ Type
|
WP10.336
|
||
|
♦ Rated power (Kw/rpm)
|
247
|
|||
|
♦ Max torque (Nm/rpm)
|
1250 / 1200-1600
|
|||
|
♦ Emission standard (ml)
|
9726
|
|||
|
♦ Fuel tank capacity (L)
|
400
|
|||
|
♦ Clutch
|
Monolithic the dry
|
|||
|
♦ Gearbox
|
Mechanical type
|
|||
|
♦ Brake system
|
♦ Service brake
|
Drum-type
|
||
|
♦ Auxiliary brake
|
Exhaust braking
|
|||
|
♦ Parking brake
|
Spring storage
|
|||
|
♦ Steering gear tyoe
|
Circulation ball power steering
|
|||
|
♦ Frame of vehicle type
|
Fish belly shape, variable width, variable section side beam structure
|
|||
|
♦ Axle
|
♦ Front
|
VL4/15D-7.5 integral type
|
||
|
♦ Rear
|
HD7/015DGS-13 integral type
|
|||
|
♦ Suspension
|
♦ Front
|
Leaf spring, telescopic shock absorber stabilizer bar
|
||
|
♦ Rear
|
Leaf spring, equalizing type of suspension
|
|||
|
♦ Tire
|
12.00-20
|
|||
|
♦ Cab
|
Short cab
|
|||
|
♦ Applicable mining and use
|
Mud grey, coal, dredging, sand stone, one transport
|
|||
As the most professional special purpose vehicle manufacturer in China, CEEC can produce different kinds of special purpose trucks based on client’s request:
Previous clients build samples:
