BEIBEN North Benz 14-20CBM 6x4 water sprinkler truck manufacturer

China North Benz6x4 type water tanker truck use WEICHAI WP10.336 engine, emission standard 9726ml, can meet Euro Ⅱ/Ⅲ. The service brake is drum type, which makes traveling more safety. Wheelbase is 5050+1450mm. 12.00-20 tire as the standard configuration, but consumers can have 12.00R20 tire or tubeless tire for optional.

The 14-20CBM Beiben water sprinkler truck has following standard configuration: former blunt sprinkling, take lateral jet and rear sprinkled in the rear of tank, rear work platform, platform after install greening sprinkling, guns can rotate 360 degrees, but even after adjusting heavy rain, rain, drizzle, mist shape, straight strong shape, range 30 meters. Use fire interface to make self-priming.

Following showing technical specification for beiben North Benz 6x4 sprinklers truck:

Name	BEIBEN North Benz 6x4 14-20CBM  water sprinkler truck
Drive Type	6x4 LHD(RHD is optional)
wheelbase(mm)	5050+1450
Engine	WEICHAI WP10.336
Horspower	336HP/247KW
Emission standard	EURO III
Displacement	9.726L
Transmission	12JS160T
Steering	TAS85
Front axle	BENZ 7.5Ton
Drive axle/ratio	BENZ 13 Ton double reduction axle/5.263
Frame(mm)	300x90x8+6+8
Leaf spring	13/13
Tyre	12.00-20(12.00R20 is optional)
Front/Rear hang (mm)	1410/2505
Front/Rear Trackmm)	1995/1800
Cabin	Short cab, made by full steel material, anticrash performance can be ensured by double hollow chamber structure. Inner A/C
Clutch	430mm, hydraulically operating with air assistance
Overall size(mm)	10415×2500×3340
Curb weight(kg)	12610
Total mass(kg)	25000
Max speed	90km/h
Brakes	Brake gap can be adjusted automatically, double circulation air brake system  Auxiliary brake: engine exhaust brake
Other detail specifications	1.     End Cap material thickness:5mm 2.     Material thickness:5mm 3.     Number of baffles:3 4.     Baffle material thickness:4mm 5.     Manhole Qty:1 6.     Manhole size:500mm 7.     Rear spray: Double adjustable spray nuzzle (Duck mouth shape) 8.     Pump discharge capacity: 1000 litres/min 9.     Pump type: 80YHCB-60 PTO driven 10.  Suction port: 80mm 11.  With Ladder
Electrical system	Battery : 2X12V/135Ah
	Generator : 28V-35A
	Starter : 5.4Kw/24V

 Previous clients build samples:
