FOTON 4,000 liters vacuum tanker truck, FOTON 4x2 Right Hand Drive chassis, 6-shift manual gearbox, CUMMINS 141HP diesel engine, strong vacuum tanker, famous brand vacuum pump, all painting and logos depend on requirement.
Applications:
FOTON Vacuum Tanker Truck (also called vacuum
sewage truck, FOTON 4×2 sewer cleaner truck, FOTON vacuum truck, FOTON
septic tanker truck, FOTON 6 wheeler vacuum suction truck, vacuum tanker
truck manufacturer) is used to collect, transport and discharge liquid such as dirty water,
sludge, septic, crude oil, and solid stuff such as small stones, bricks
as well. It is suitable for cleaning the sewer, cesspit, cesspool,
gully, etc. It is widely used in environment and sanitation field.
CEEC TRUCKS Vacuum truck is equipped with WEILONG or Italy BP vacuum pump, for 10CBM
or more recommend Double Pump for efficiently working.
The septic pump truck can be equipped with cabin Pneumatic Control for easy operation.
Key Features:
---- FOTON chassis, perfect performance
---- CUMMINS engine option, super powerful, no overhaul within 100,000 km.
---- Vacuum Tanker body capacity from 3 to 20 Cublic Meter.
---- Easy operation and easy maintenance.
---- Various types of refuse container lifter are available.
Specifications:
FOTON Septic tanker Truck (4000 liters) |
||
General |
Vehicle Brand |
CEEC |
Chassis Brand |
FOTON |
|
Overall Dimension |
5900 * 2250 * 2650 mm |
|
GVW / Kerb Weight |
7,000kg / 4,500kg |
|
Cab |
Cab Capacity |
3 persons allowed |
Air Conditioner |
Heating/cooling air conditioner |
|
Engine |
Fuel Type |
Diesel |
Engine Brand |
CUMMINS |
|
Power |
141 HP (105 KW) |
|
Displacement |
3760 ml |
|
Emission Standard |
Euro 3 |
|
Chassis |
Drive Type |
4X2 (right hand drive) |
Transmission |
6-shift speed levers with 1 reverse |
|
Wheelbase/No. of axle |
3360 mm / 3 |
|
Tire Specification |
7.00R16 |
|
Tire Number |
6 tires and 1 spare tire |
|
Max Speed |
90 km/h |
|
Paint |
Metallic paint |
|
Superstructure |
Body capacity |
4,000 Litres |
Tanker Material |
Carbon Steel |
|
Suction Head pipeline |
7 m |
|
Vacuum Pump brand |
WEILONG / Italy BP / Domestic Pump |
|
Vacuum Pump advantage |
High efficient, vacuum rate 93%,
quick suction and discharge, suction lift 6m |
|
Hose |
High quality, wire strengthened hose |
|
Control panel |
English or Your language |
|
All standard accessories: Inlet pipeline, discharge nozzle, cabin pneumatic control box, basic tool kit, English manual…… |
||
Optional |
** Back alarm and Camera can be equipped. ** Standard carbon steel, stainless steel optional. ** Standard WEILONG vacuum pump, Italy vacuum pump optional |
Vacuum Trucks |
|||
Model |
Engine Model |
Rated Power |
Payload |
Driving Model |
4KH1CN5LS |
98 HP |
6,000 L |
4×2 |
|
4HK1-TC51 |
190 HP |
8,000 L |
4×2 |
|
4HK1-TC50 |
205 HP |
10,000 L |
4×2 |
|
WD615.30 |
300 HP |
10,000 L |
6×4 |
|
WD615.34 |
340 HP |
20,000 L |
6×4 |
|
CEEC5200-ZZ |
WD615.38 |
380 HP |
20,000 L |
6×4 |
(Professional vacuum suction trucks manufacturer)
CEEC TRUCKS is a professional vacuum tanker trucks manufacturer. We can provide ISUZU vacuum sewage truck, HOWO vacuum truck, FOTON sewer sucker truck, Dongfeng septic tanker truck, etc. The capacity of vacuum tankers can be 3,000-20,000 liters. Our vacuum sewage trucks are very popular in Southeast Asia, Middle East, Africa and South America because of the high quality and low price.
Factory Advantage
CEEC TRUCKS is a leading exporter of ISUZU septic tanker trucks in China. We possess over 10-year export experience of vacuum suction trucks. We can ensure the fast delivery time and 12 months guarantee for our vacuum trucks. Our vacuum tanker trucks are sold to more than 80 countries including Eastern Europe and CIS countries, Africa, Southeast Asia, Central and South America, Middle East, etc.
---- Professional guidance on your importing documents.
---- Maximize save your sea freight.
---- Safety, Quickly, Timely
