ISUZU 10CBM Rear load compactor truck
High compaction ratio ISUZU refuse compactor truck, the truck chassis use ISUZU 190HP diesel engine, ISUZU MLD 6-shift transmission gear. PLC control box for easy operation. All painting and logos based on client's requirement.
Product Origin:
China CEECShipping Port:
China Main PortLead Time:
20 DaysPayment:
T/T, West Union
Applications:
ISUZU 10CBM Back Loading garbage truck (also called ISUZU garbage compactor, back loading bin truck, ISUZU waste disposal truck, rear loader refuse truck, rubbish compactor truck, garbage compactor manufacturer) is designed for daily rubbish transport in such living areas as all kinds of cities, large station, port and wharf, airport, and densely-populated areas like industrial and mineral enterprises and military units.
CEEC TRUCKS compressed refuse truck reduces back-and-forth transport times and prevents rubbish and stinks from spreading and avoids second-time pollution produced by polluted water.
The refuse compactor vehicle tail-gas discharge reaches EUROPEAN standard. which is safe and environmental-protective.
Key Features:
---- ISUZU chassis, perfect performance
---- ISUZU engine, super powerful; reliable performance, no overhaul within 100,000 km.
---- Compactor body capacity from 3 to 20 Cublic Meter.
---- Easy operation and easy maintenance.
---- Various types of refuse container lifter are available.
Specifications:
|
ISUZU Compression garbage truck (10 cbm) |
||
|
General |
Vehicle Brand |
CEEC TRUCKS |
|
Chassis Brand |
ISUZU |
|
|
Overall Dimension |
7900 * 2300 * 2850 mm |
|
|
GVW / Kerb Weight |
11,000kg / 5,800kg |
|
|
Cab |
Cab Capacity |
3 persons allowed |
|
Air Conditioner |
Heating/cooling air conditioner |
|
|
Engine |
Fuel Type |
Diesel |
|
Engine Brand |
ISUZU |
|
|
Power |
190 HP (141 KW) |
|
|
Displacement |
5193 ml |
|
|
Emission Standard |
Euro 5 |
|
|
Chassis |
Drive Type |
4X2, (left hand drive) |
|
Transmission |
ISUZU MLD 6 speed levers with 1 reverse |
|
|
Wheelbase/No. of axle |
4175 mm / 2 |
|
|
Tire Specification |
8.25R16 |
|
|
Tire Number |
6 tires and 1 spare tire |
|
|
Max Speed |
95 km/h |
|
|
Paint |
Metallic paint |
|
|
Superstructure |
Body capacity |
10 cbm |
|
Fill Hopper capacity |
1.2 cbm |
|
|
Sewage tank |
200 liters |
|
|
Filling work cycly time |
20~25 s |
|
|
Discharge model |
Horizontal Ejection |
|
|
Control system |
Electrically Hydraulic control Manual hydraulic control |
|
|
Control panel |
English or Your language |
|
|
All standard accessories: Dust bin lifter,Ladder, warning lights, Emergency stop button, handrail, fire extinguisher, basic tool kit, English manual…… |
||
|
Optional |
** Back alarm and Camera can be equipped. ** Italy mulit-valve can be choose. ** 240L (single bin or double bin) or standard 660 L, 1100 L bins with bin lifter can be choose. |
|
(China premium refuse compactor truck manufacturer, 26 units garbage compression trucks were delivered)
Garbage Compactor Trucks |
|||
|
|
|
|
|
|
|
|
Model |
Engine Model |
Rated Power |
Capacity |
Driving Model |
4KH1CN5LS |
98 HP |
4×2 |
||
4KH1CN5HS |
130 HP |
4×2 |
||
WP4.180 |
180 HP |
4×2 |
||
4HK1-TC50 |
205 HP |
4×2 |
||
B190 33 |
190 HP |
4×2 |
||
WD615.71 |
260 HP |
6×4 |
||
6HK1-TCH |
300 HP |
6×4 |
||
ISLe340 30 |
340 HP |
6×4 |
||
6UZ1-TCG50 |
380 HP |
6×4 |
CEEC TRUCKS is a professional garbage compactor trucks manufacturer. We can provide ISUZU refuse compactor truck, HOWO rear loader refuse collection truck, Dongfeng waste compressor truck, FOTON back loading bin truck. Our garbage compactor trucks are very popular in Southeast Asia, Middle East, Africa and South America because of the high quality and low price. In addition, CEEC also manufacture fuel tanker trucks, water tanker trucks, vacuum sewage trucks, street sweeper trucks, etc.
